Refrigerant Infrared Gas Sensor – Platinum Series
Contact our experienced engineers to discuss your application needs.
Details
-
Dynament refrigerant gas sensors are available for a wide range of gases, including R32, R454B, R454C, R290, and R744 (CO₂), supporting diverse HVACR applications.
-
Independently evaluated by AHRTI, these sensors successfully passed all performance tests outlined in the 2020 report: Refrigerant Detector Characteristics for Use in HVACR Equipment.
-
Capable of detecting refrigerant gases within the Lower Flammability Limit (LFL) range, they deliver a high-resolution output of 0.05% (500 ppm) for precise leak detection.
-
Each sensor offers plug-and-play integration, combining optics, electronics, and firmware to deliver a linearized, temperature-compensated signal streamlining system development and reducing time to market.
-
Dynament’s USB-powered Premier Configuration Unit allows for fast sensor setup, calibration, and parameter customization. Included PC software supports data logging and diagnostics.
-
Manual calibration can also be performed without the need for digital communication, offering added flexibility in the field.
-
Designed with robust electromagnetic compatibility (EMC) shielding to ensure reliable performance in electrically noisy environments.
-
Based on proven non-dispersive infrared (NDIR) technology for stable, accurate refrigerant gas sensing over long operating lifetimes.
